| CELL |
EQUIPMENT |
Specification |
PROCESS |
| Large Size Casing Cell |
CNC Lathe |
Stroke : 2028 / Swing : ø770 / Tool A.T.C : 12EA |
Turning Drilling / Tapping |
| CNC Vertical Turn Mill Center |
Table:ø1600×H1600 / Swing:ø2000 / Tool A.T.C : 24EA |
Turning Drilling / Tapping |
| CNC Plano Miller Machining |
Table : 2000×4000×H2100 / Tool A.T.C : 60EA |
Plano miller Milling / Drilling Tapping |
| Horizontal Boring and Milling Machining Center |
Table : 1400×1600 / Tool A.T.C : 60EA |
Boring Milling / Drilling Tapping |
| Complex Machining Center |
Table : ø630 / A.P.C. : 2EA / A.T.C : 36EA |
Boring Milling / Drilling Tapping |
| Frame Cell |
Horizontal Machining Center |
Table : 630×30×H800 / A.P.C. : 2EA / A.P.C : 80EA |
Horizontal Machining/center |
| Impeller Cell |
CNC Lathe PUMA 10S |
Stroke : 7701 / Swing : ø580×7701 / Tool A.T.C : 8EA |
Turning |
| Slotting Machine |
Stroke : 280mm |
Key Way |
| Balancing Machine |
Weight under uniform load : 1000kg / Rotor diameter : 1500mm |
Balance |
| Shaft Cell |
CNC Lathe |
Stroke : 1500I / Swing : ø510 / Tool A.T.C : 12EA |
Turning |
| Double Column Machining Center |
Table : 1740×650×H460 / Stroke(X.Y.Z): 1500×700×460 Tool A.T.C: 30EA |
Key Way |
| CNC Cylindrical Grinding Machine |
Wheel : ø510×75mm 30m/s / Swing : ø400 / Stroke : 1500I |
Grinding |
| Small,Middle size Part Cell |
CNC Vertical Turning |
Table : ø500 / Deinh : ø800 / Tool A.T.C : 6EA / Stroke : 500 |
Turning |
| Double Column Machining Center |
Table : 1740×650×H460 / Stroke(X.Y.Z): 1500×700×460Tool A.T.C: 30EA |
Milling Drilling / Tapping |
| Automatic Picking System |
Automatic Picking System (HYUNDAE, KOREA) |
Load Size : 1000W×1200L×1000H / Load Weight : MAX 1000kg/PLT
Locations : 4Row×31Bay×16Leveld = 1984 cell / Stacker crane : 2set (MURATA, JAPAN)
Picking : Balance Liffer / Robo-Train : RTN / Computer H/W : RS/6000-25T
DBMS : Oracle C. Language |
| Small,Middle size Part Cell |
5-Axis Multi-Tasking Machining Center (MATSUURA, JAPAN) |
A, C - Axis Travel : -120~+30deg×360deg
Table Working Surface : ø500mm
Spindle Speed Range : 40~12,000 min-1
A.P.C : 11EA / A.T.C : 240 EA |
Turning/Milling/Boring Milling |
